| AFUE Rating | : | 80 % |
| Amperage Rating | : | 8 A |
| Blower Size | : | 9-41/64 in H x 11-3/16 in D |
| Cabinet Dimensions | : | 33-3/4 in H x 17-1/2 in W x 24-13/16 in D |
| Configuration | : | Down Flow, Horizontal, Up Flow |
| Frequency Rating | : | 60 Hz |
| Fuel Type | : | Natural Gas, Propane |
| HP Rating | : | 1/2 hp |
| Ignition System | : | Hot Surface |
| Input BTU Rating | : | 80000 Btu/hr |
| Material | : | Steel |
| Model | : | AGF80 |
| Motor Type | : | ECM |
| Number of Burners | : | 5 |
| Number of Speeds | : | 5 |
| Output BTU Rating | : | 64000 Btu/hr |
| Rotational Speed | : | 1050 rpm |
| Temperature Rise | : | 30 to 60 deg F |
| Vent Size | : | 3 in, 4 in Dia |
| Vent, Ducted or Ductless | : | Vent |
| Voltage Rating | : | 115 V |
Introducing Tuttokool's robust furnace line, designed to deliver dependable warmth when the temperatures drop. Built with a commitment to enduring performance, our furnaces ensure consistent heating that you can rely on year after year. Embrace superior heating solutions with Tuttokool, where quality craftsmanship meets lasting comfort.
Tuttokool Gas Furnace, AGF80 Model, 80000 Btu/hr Input BTU Rating, 64000 Btu/hr Output BTU Rating, 115 V Voltage Rating, 8 A Amperage Rating, 1/2 hp Rating, 80 % AFUE Rating, 60 Hz Frequency Rating, Down Flow, Horizontal, Up Flow Configuration, Natural Gas, Propane Fuel Type, 5 Number of Burners, 5 Number of Speeds, 9-41/64 in H x 11-3/16 in D Blower Size, 33-3/4 in H x 17-1/2 in W x 24-13/16 in D Cabinet Dimensions, ECM Motor Type, 1050 rpm Rotational Speed, Vent Vent, Ducted or Ductless, 3 in, 4 in Dia Vent Size, Hot Surface Ignition System, Steel, 30 to 60 deg F Temperature Rise
- Durable aluminized steel tubular heat exchanger. Hot-surface ignition for dependable operation
- Quiet multi-speed direct-drive Blower
- Natural gas and propane (LP) convertible
- Industry-standard cabinet sizes for easy replacement, installation and add-on cooling
- Convenient left or right connection for gas and electric service
- Removable bottom for side or bottom return application
- Designed for multi-position installation: Up flow, down flow, horizontal
