| Amperage Rating | : | 4.5 A |
| BTU Rating | : | 48000 Btu/hr |
| CFM Rating | : | 400 cfm |
| Configuration | : | Upflow, Downflow, Horizontal Left or Right |
| Connection Type | : | 3/8 in Liquid, 7/8 in Suction |
| Dimensions | : | 22 in W x 24 in D x 54-1/2 in H |
| Filter Size | : | 20 x 22 in |
| Finish | : | Galvanized/Painted |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 3/4 hp |
| Material | : | Aluminum/Steel |
| Model | : | BVA |
| Motor Type | : | ECM Blower |
| Phase | : | 1 ph |
| Series | : | A Series |
| Sound Level | : | 59 to 67 dBA |
| Temperature Rating | : | -4 to 125 deg F |
| Voltage Rating | : | 208 to 230 VAC |
BOSCH Indoor Multi-Position Vertical Air Handler, A Series, BVA Model, 48000 Btu/hr BTU Rating, 208 to 230 VAC Voltage Rating, 4.5 A Amperage Rating, 3/4 hp Rating, 60 Hz Frequency Rating, 1 ph Phase, 400 cfm Rating, Upflow, Downflow, Horizontal Left or Right Configuration, Connection Type: 3/8 in Liquid, 7/8 in Suction, 59 to 67 dBA Sound Level, 20 x 22 in Filter Size, ECM Blower Motor Type, Aluminum/Steel, Galvanized/Painted, -4 to 125 deg F Temperature Rating, 22 in W x 24 in D x 54-1/2 in H Dimensions
- Premium efficiency - up to 20.5 SEER, up to 10.5 HSPF
- All aluminum evaporator coil for superior corrosion resistance
- Constant torque multi-speed ECM blower motor - designed for two-stage operation
- Easy-to-install - compatible with most standard 24 VAC heat pump thermostats
- Factory-installed TXV metering
- Multiple electrical entry locations
- Dual front panel design for ease of maintenance
- Blower and coil easy slide-out for ease of maintenance
- Fully insulated cabinet design
- Horizontal and vertical condensate drain pans standard
- Condensate drain pan is polymer with UVC inhibitor
- Primary and secondary condensate drain fittings
- Factory sealed cabinet certified to achieve 2% or less air leakage rate at 1 Inch water column
- Integrated filter rack with tool-less door access
- 10 years limited warranty
