| Amperage Rating | : | 6.3/7 A Cooling, 8.3/9.3 A Heating |
| BTU Rating | : | 17200 Btu/hr Cooling, 21600 Btu/hr Heating |
| CFM Rating | : | 695 cfm |
| Compressor Type | : | DC Twin Rotary |
| Connection Type | : | Flared |
| Dimensions | : | 27-3/8 in H x 34-15/32 in W x 12-5/8 in D |
| Drive Type | : | Direct DC Brushless Motor |
| EER Rating | : | 13.2 |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 20 A |
| HSPF Rating | : | 9, 6.9 |
| Liquid Line Size | : | 1/4 in |
| Mounting Type | : | Wall |
| Phase | : | 1 ph |
| Power Rating | : | 1300 W Cooling, 1750 W Heating |
| Refrigerant Type | : | R-410A |
| Rotational Speed | : | Variable |
| SEER Rating | : | 19.5 |
| Sound Level | : | 47 dBA High, 39 dBA Medium, 36 dBA Low |
| Suction Line Size | : | 1/2 in |
| Voltage Rating | : | 208/230 VAC |
The Panasonic exteriors E Series is a deluxe line of wall-mounted single zone heating and cooling mini-split air conditioners. With energy efficiency and -5 deg F heating operation, these models are often selected for rebate programs and cold climate solutions. ECONAVI sensor technology manages energy efficiency and comfort by continually scanning for occupancy and vacancy.
Panasonic Outdoor Single Exteriors E Cool and Heat Pump, 208/230 VAC Voltage Rating, 6.3/7 A Cooling, 8.3/9.3 A Heating Amperage Rating, 1300 W Cooling, 1750 W Heating Power Rating, 60 Hz Frequency Rating, 1 ph Phase, Variable Rotational Speed, 17200 Btu/hr Cooling, 21600 Btu/hr Heating BTU Rating, 695 cfm Rating, 13.2 EER Rating, 19.5 SEER Rating, 9, 6.9 HSPF Rating, Connection Type: Flared, DC Twin Rotary Compressor Type, R-410A Refrigerant Type, 1/4 in Liquid Line Size, 1/2 in Suction Line Size, 20 A Fuse Rating, Direct DC Brushless Motor Drive Type, 47 dBA High, 39 dBA Medium, 36 dBA Low Sound Level, Wall Mounting Type, 27-3/8 in H x 34-15/32 in W x 12-5/8 in D Dimensions
- -5 deg F cold climate heat operation, cooling only operation - configure during installation
- ECONAVI energy savings and comfort through sensor technology
