| BTU Rating | : | 36000 Btu/hr |
| Configuration | : | Downflow, Left, Right, Upflow |
| Model | : | D5FUAA |
| Nominal Capacity | : | 3 ton |
| Pressure Rating | : | 0.8 in-WG |
| Refrigerant Type | : | R-454B |
| Series | : | Performance Series |
| Sound Level | : | 25.5 dB |
| Voltage Rating | : | 115/208/230 V |
The D5FUAA air handler offers is an adaptable solution that can be installed in both horizontal and vertical installations. This unit can connect to the D5CUHA or D5CURA heat pump for single-zone applications.
HEIL® Air Handler, Series: Performance Series, Model: D5FUAA, 3 ton Nominal Capacity, 36000 Btu/hr, 115/208/230 V, Downflow, Left, Right, Upflow Configuration, R-454B, 25.5 dB, 0.8 in-WG
- Sizes: 18 / 24 / 30 / 36 / 48/ 60
- Modes: Cool, Heat, Dry, Fan, Auto
- 4-way installation (Up flow, Down flow, Right, Left)
- All aluminum coil for corrosion-resistance
- Automatic Airflow Technology with static pressure up to 0.8 in WG
- Less than 2% air leakage
- Easy maintenance
- Quiet indoor operation
- Wireless remote control included
- 24V interface for third party thermostat compatibility built-in
- Factory installed leak detection system (sensor and control board)
- EHKMC (5-25 KW): Auxiliary heater (optional accessory)
- 10-Year Parts Limited Warranty
