| Average Arrestance | : | 93 % |
| Depth | : | 1 in |
| Filter Efficiency | : | 30 to 35 % |
| Final Resistance | : | 1 in-WG |
| Height | : | 21-5/8 in |
| Initial Resistance | : | 0.17 in-WG at 300 fpm |
| MERV | : | 8 |
| Media Area | : | 300 to 399 sq-in |
| Media Material | : | Non-Woven Synthetic |
| Pleats per Linear Feet | : | 13 |
| Rated Velocity | : | 300/500 fpm |
| Series | : | 80055 Series |
| Temperature Rating | : | 180 deg F |
| Width | : | 16-1/2 in |
Flanders® Pleated Air Filter, 80055 Series, Non-Woven Synthetic Media, 16-1/2 in Width, 21-5/8 in Height, 1 in Depth, 8 MERV, 30 to 35 % Filter Efficiency, 300 to 399 sq-in Media Area, 13 Pleats per Linear Feet, 300/500 fpm Rated Velocity, 0.17 in-WG at 300 fpm Initial Resistance, 1 in-WG Final Resistance, 93 % Average Arrestance, 180 deg F
- Media is made of 100% synthetic non-woven proprietary media that can be recycled
- The media is supported by an expanded metal continuously laminated on the air leaving side to provide pleat stability while eliminating flutter
- Pleat design is a V-pleat that aids in pressure drop while reducing energy cost and allowing total media usage and provides maximum airflow and dust holding capacity
- Frame is a two piece construction, made of a heavy-duty 24 point moisture-resistant material
- Diagonal and horizontal support members are bonded to the media on both sides
- Highest dust holding capacity and lowest pressure drop-in the industry
- 40% low pressure drop
